ASUS TUF Gaming Charger 150W Pin Size: Everything You Need to Know

If you own an ASUS TUF Gaming laptop and wish to change your charger or get a backup, one of the most crucial things to check for is the 150W charger pin size. If you choose the wrong connector size, your device may not charge correctly, your charger may not fit, or even hardware damage may occur. The correct pin size for the ASUS TUF 150W charger, model compatibility, replacement buying tips, and possible issues are all covered in this tutorial. Whether you’re an IT support specialist, computer enthusiast, or gamer, we’ll help you make an informed decision.

What is the pin size of the ASUS TUF Gaming 150W Charger?

The pin measurements of the ASUS TUF Gaming 150W charger are 2.5 mm for the inner diameter and 5.5 mm for the outside diameter. This barrel-style connector is found on many ASUS TUF models, especially the mid-range and high-performance gaming laptops.

However, it’s important to confirm the specs for your individual model. The power input requirements of some TUF series variants, such as those with AMD Ryzen processors or NVIDIA RTX graphics cards, may differ.

How to Measure the Charger Pin’s Size

  • Look at the charger’s original label. The voltage, current, and sometimes the connection size are listed (19.5V 7.7A, for example).
  • Use a digital caliper to measure the barrel if the label is missing.
  • Go to the ASUS support page to determine your exact model.

ASUS TUF models that work with 5.5×2.5mm chargers that have a 150W capacity

The FX505DT, FX505DU, and FX505DY are among the ASUS TUF Gaming laptops that are compatible with the 150W 5.5×2.5mm pin charger. Series: ASUS TUF Gaming F15/FX506 ASUS TUF Dash F15 (prior 150W variants) ASUS TUF Gaming ASUS FA506/TUF A15 Series

Always verify compatibility with your device’s model number. Using the wrong charger can lead to poor performance, overheating, or instability in the system.

Suggestions for Buying an Alternative to ASUS’s TUF 150W charger

  1. Keep utilizing original or approved OEM chargers.
    Avoid using generic or unbranded chargers. Although they are less costly, they usually lack sufficient voltage regulation or safety features.
  2. Look for These Specifics:
    • It has an output of 19.5V.
    • Currently, 150W of electricity at 7.7A.
    • Connector: 5.5 x 2.5 mm.
  3. Seek Safety Certifications
    UL, CE, FCC, and RoHS certifications all attest to safe production practices.
  4. Verify the Plug Type (Pin Size).
    When making an online purchase, product listings should clearly state the barrel measurements. Some sellers even include close-up pictures or diagrams.
  5. Use Trustworthy Sellers and Brands
    ASUS (Representative) Electronics is one of the reliable brands. It offers appropriate advice for universal chargers, Delta, Chicony, and Targus.

Additional Considerations When Choosing a Laptop Charger

Sturdiness and Quality of Construction

To withstand repeated use, a high-quality charger should have a robust shell, reinforced cable joints, and high-quality internal components. Thick rubberized or braided cables are more resilient and less likely to break, particularly if you travel regularly or move your laptop around a lot.

The charger cable’s length

The usual wire length is between 1.5 and 2 meters. Consider longer cables for greater flexibility or shorter cords for small desk configurations, depending on how your workspace is organised.

Portability and Convenience for Travel

A compact and lightweight 150W charger may be useful for frequent travellers. Some third-party manufacturers offer portable, slim-profile chargers without compromising functionality. Seek out foldable plugs and cable organizers.

Managing the Heat

Overheating is one of the most common reasons why chargers malfunction. Verify that the charger has a built-in temperature control system or overheat prevention. Couches, mattresses, and other soft surfaces with poor ventilation shouldn’t be charged.

Real-World Applications: Pin Size’s Significance

In reference to gamers:

Laptops used for gaming use a lot of electricity. Using a charger with the wrong pin size or lower wattage can cause performance throttling, reduced frame rates, or battery loss while playing.

For Students & Professionals:

Using the incorrect adapters could cause random shutdowns when working or giving presentations. Making sure you have the appropriate charger boosts productivity and reduces downtime.

Concerning IT Managers:

Managing the inventory of a fleet of ASUS TUF laptops? The proper pin size ensures seamless device swaps and lowers support tickets.

For an enthusiast of do-it-yourself repairs:

If you feel comfortable making hardware repairs or computer modifications, knowing pin size is crucial when changing power jacks, building custom docks, or adding alternative power sources.

Typical Charger Problems and Fixes

There was no charger found.

Verify that the pin is firmly attached. If not, the barrel may be bent, loose, or misaligned. Try comparing it to another charger or slowly twisting the plug.

Slow charging or no charge:

Check the wall plug and power strip. If another laptop is accessible, use it for testing. Examine the charger brick for LED status indicators. Check for exposed wires, fraying, or heat damage.

The charger warms up quickly.

A little heat is normal, especially when under load. However, significant heat points to potential short circuits, poor construction, or internal degeneration. Replace it immediately to prevent damage to the hardware.

A variable source of power:

Damaged wires or incorrect pin connections typically cause this. Repairing tape is dangerous and only lasts a short time. Replace the charger.

Internal and external connections as well as resources:

  • The Best Gaming Laptops of 2025
  • The Greatest Safety Tips for Laptop Chargers
  • An Overview of Laptop Power Supply Ratings

External Resources:

  • UL Certifications
  • Official ASUS Support Directory
  • How to Measure Charger Plug Sizes (YouTube)

READ MORE – Ultimate Guide to the 510 Thread Charger: What You Need to Know in 2025

FAQs:

  1. What is the exact pin size of the ASUS TUF Gaming 150W charger?
    Typically, the inner diameter of a pin is 2.5 mm, and the outside diameter is 5.5 mm.
  2. Can I use a 180W charger instead of a 150W one for my ASUS TUF?
    Yes, as long as the voltage and pin size match. Higher wattage is safe, but lower wattage is dangerous.
  3. Are universal chargers safe to use with ASUS TUF laptops?
    Yes, as long as they can handle the required voltage and pin size. Always verify compatibility before using.
  4. What happens if I select the wrong pin size?
    Inadequate power delivery, overheating, or an inability to fit the charger could damage the hardware or cause performance issues.
  5. How can I tell if my charger is malfunctioning?
    Watch for signs like excessive warmth, sluggish charging, or frequent disconnections.

Conclusion:

Choosing the correct charger for your ASUS TUF Gaming laptop is crucial to ensuring reliable operation and long-term dependability. Although 5.5 x 2.5 mm is a common pin size for many 150W versions, checking with your specific device type is crucial. Avoid taking shortcuts with subpar or generic adapters. Instead, prioritize brand reputation, safety, and compatibility. By doing this, you can keep your device running at its peak performance and extend its lifespan when working, studying, or playing games.
